Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in making construction equipment. They produce machinery like boom lifts, aerial lifts and manlifts. These equipments are designed to facilitate access to difficult to reach areas, buildings and roofs, large equipment, among other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration refers to a power-driven endless belt. This belt only moves in one direction and contains platforms, or steps or handholds that are connected to the unit to be able to move workers from each floor.
TB85
The Terex TB85 offers a maximum working height of 91 feet. In addition, the maximum height of the platform reaches 85 feet. This model's maximum width is 8 feet, 1 and 1/2 inches. The TB85 has dimensions which measure 9 inches wide and 9 feet, 1-inch high by 36 feet. This particular model offers a reach of seventy feet. The TB85 has a boom angle below horizontal measures at -14 degrees and above horizontal reaching 75 degrees.
Terex TB100
The Terex TB100 man lift's maximum height is 106 feet and the platform's maximum height is 100 feet. The TB100 when stowed away, is roughly 8.5 feet wide by 9 feet high by 8 feet. The unit's maximum width is 8 feet, 1 1/2 inches. The boom angle above horizontal is 75 degrees and below horizontal is 14 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The Terex TB110 man lift reaches a max height of 100 feet, whilst the max working height measures at 116 feet. The model is 8 feet wide x 9 feet, 4 inches high The TB110 provides a horizontal reach of 67 feet and a maximum width of 8 feet. This particular model has a boom angle of 75 degrees above horizontal plus 10 degrees articulating. Below horizontal it is -14 degrees and it measures -105 degrees articulating.
